Therefore, the operations of the microprocessors used in the machines are not discussed: they are explained in terms of from sensors to the input of the DC controller PCB and from the output of the DC controller PCB to the loads. In practically all cases, the internal mechanisms of a microprocessor cannot be checked in the field. (The voltage value, however, differs from circuit to circuit.) In addition, the asterisk (*) as in "DRMD*" indicates that the DRMD signal goes on when '0'. In the digital circuits, '1' is used to indicate that the voltage level of a given signal is "High", while '0' is used to indicate "Low". The expression "turn on the power" means flipping on the power switch, closing the front door, and closing the delivery unit door, which results in supplying the machine with power.Ģ. In the diagrams, represents the path of mechanical drive where a signal name accompanies the symbol, the arrow indicates the direction of the electric signal. Each chapter contains sections explaining the purpose of specific functions and the relationship between electrical and mechanical systems with reference to the timing of operation. The following rules apply throughout this Service Manual:ġ. Set the cable/wire to the cable guide or wire saddle. Remove the cable/wire from the cable guide or wire saddle.
#Canon super g3 printer fax manual manual
Under the copyright laws, this manual may not be copied, reproduced or translated into another language, in whole or in part, without the consent of Canon Inc.ĬautionUse of this manual should be strictly supervised to avoid disclosure of confidential information.Įxplanation of SymbolsThe following symbols are used throughout this Service Manual.Ĭonnect the connector. TrademarksThe product names and company names used in this manual are the registered trademarks of the individual companies.ĬopyrightThis manual is copyrighted with all rights reserved. The following paragraph does not apply to any countries where such provisions are inconsistent with local law. In the event of major changes in the contents of this manual over a long or short period, Canon will issue a new edition of this manual.
When changes occur in applicable products or in the contents of this manual, Canon will release technical information as the need arises.
For this reason, there may be information in this manual that does not apply to your locality.ĬorrectionsThis manual may contain technical inaccuracies or typographical errors due to improvements or changes in products. This manual covers all localities where the products are sold.
for qualified persons to learn technical theory, installation, maintenance, and repair of products. ApplicationThis manual has been issued by Canon Inc.
